Concrete Spraying Machine Similar to Western Shotcrete Equipment
Automatically work mortar concrete spraying machine cost
ZT40 concrete spray system is equipped with an automatic system for high precision synchronization between the concrete pump and the additive dosing unit, thereby assuring spraying accuracy and quality. All the machine functions are available via the remote control, which facilitates the operator's work.
ZT40 Concrete spraying system is a concrete spraying system specially developed for use in mines, tunnels, and outdoor construction.
Applications & Features Of Concrete Spraying System:
1. For use in mines, tunnels, and outdoor construction.
2. With a robot telescope arm, Pumping and Spraying concrete automatically.
3. An automatic system for high precision synchronization between the concrete pump and the additive dosing unit
4. All the machine functions are available via the remote control, which facilitates the operator's work.
5. The six-wheel-drive increases its perfect maneuverability in difficult driving situations.
ZT40 Concrete Spraying Machine Technical Parameters:
| ZT40A | ZT40B | |||
| Dimensions | LxWxH | Mm | 9900x2290x2950 | 9900x2290x3700 |
| Weight | Net Weight | Kg | 21, 500 | 25, 000 |
| Boom | Boom structure | The main arm rotate, Telescope | Main arm rotate, Spray arm fold, Telescope | |
| Spray vertical distance | M | 14 | 20 | |
| Spray horizontal distance | M | 2x11 | 2x17 | |
| Arm stroke | M | 4.5 | 3.5+2 | |
| Concrete pump | Rated output | M3/h | 40 | |
| Aggregate size | Mm | 15 or 25 | ||
| Drive | Drive mode | Diesel | ||
| Diesel engine power | KW | 170 | ||
| Fuel tank capacity | L | 120 | ||
| Electric motor power | KW | 52 | ||
| Compressor | Air compressor power | KW | 55 | |
| Air output | M3/min | 10.7 | ||
| Max air pressure | Mpa | 0.7 | ||
| Additive system | System pressure | Mpa | 1.6 | |
| System outlet | L/h | 10-600 | ||
| Coagulant tank capacity | L | 1000 | ||
We also have a small type of concrete spraying machine, that can meet clients' different project requirement.
Welcome to inquiry.
FAQ
1. Q: Are you a trading company or a manufacturer?
A: We are an original equipment manufacturer.
2. Q: How long is your delivery time?
A: It is according to the model and quantity.
Generally, it is 3-5 days if the machines are in stock.
It will be 15-30 days if you want to customize the machines.
3. Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer you the sample machine.
But it's not free. You need to pay for the sample and the cost of freight.
4. Q: What are your terms of payment?
A: We accept T/T, Western Union, Money Gram, Paypal, Alibaba Escrow, etc.
Payment<=USD 5000, 100% in advance.
Payment>=USD 5000, 30% T/T in advance, balance before shipment
