Overview: (quick details) |
||
|
Condition: new |
Power type: electric |
Place origin: Xi'an Shaanxi China |
|
Brand name: mining equipment |
Weight: 41kg |
Dimension:1025 X 480 X 900mm |
|
Certification: SGS ISO |
Warranty: half a year |
After service: no overseas maintenance but provide relative spare parts |
|
Voltage: 380v or as your request |
working pressure: 1.5Mpa |
horizontal delivery distance: 150m |
|
Product name: ZT-P3 |
Color: green or as your request |
vertical delivery distance: 40m |
|
Output: 9L/min |
power: 4kw |
delivery value: 3m³/h |
Supply Ability
1000 piece per month high-pressure grouting pump for sale
Packaging & Delivery
Packaging Details
wooden case or as your requirement
Port
typically board in ShangHai or for your convenience
Lead time
shipped less than 7 business days after we agreed on our corporation
Contact: Summer
Tel： +86-029-86627377
Mobile/Wechat/Whatsapp: +86 13571973823
Email: summer@ztmineequipment.com
Product Description
Introduction of Electric/Diesel Motor Concrete Pump, Hand Concrete Pump, High-Pressure Cement Grouting Pump. mine pneumatic injection pump is mainly used for coal, iron ore and other wall waterproofing, grouting works, as well as subways, tunnels, water, construction, and broken rock grouting works. Flammable, explosive, magnetic, radiation and more dust, temperature changes, and watering places are safe to use. Stepless amount adjustment, as long as controlling the air switch the size, the inlet amount can be changed,aslo the constant pressure automatic variables, namely discharge plasma volume with grouting pressure increases.
Feature of Electric/Diesel Motor Concrete Pump, Hand Concrete Pump, High-Pressure Cement Grouting Pump
1. Small size, lightweight, easy handling, moving frequently to adapt to multi-point grouting.
2. As a result of pressure transmission, the pump is very suitable for grouting performance and requires a large flow when low pressure and grouting pressure rise to need small flow conditions.
3. Due to pneumatic drive, so flammable, high-explosive, water spray, dust, and a large working environment can be used.
4. Under the conditions of the slurry is not very stringent, the use of one pump can achieve double grouts, greatly reducing the construction cost of equipment purchasing.
Range of application
1 in construction, use vertical or horizontal conveying mortar.
2. in the iron and steel metallurgy sector, used for the maintenance of the blast furnace and other equipment.
3. in defense engineering, civil air defense engineering, and mining, tunnel construction for grouting.
4. in the chemical sector, used to transport slurry materials (colorants, coatings), magnetic materials, and other media.
5. in the farmland water conservancy projects, used to reinforce the dam. Sand wells are used to reinforce walls and so on.
6. in the railway construction, used for bridges, culverts grouting.
7. in the thermal power plant fly ash is used for conveying mortar.
8. prestressed member works for mortar injection dilation.
9. in the highway pavement maintenance for cement concrete pavement void beneath grouting.
Main Parameter of Electric/Diesel Motor Concrete Pump, Hand Concrete Pump, High-Pressure Cement Grouting Pump
|
Type |
ZT-P3 |
|
Output |
9L/min |
|
No. of Cylinder |
2 |
|
Hose Inner Size |
dia. 32mm |
|
Operating Air Pressure |
4 MPa |
|
Voltage |
380V or as Your Request |
|
Net Weight |
0.5 tons |
|
Dimension(L*W*H) |
1025*480*900 |
1. Preparation before starting
(1)Check whether the connection parts are loose and whether there is enough oil in the gearbox.
(2)Check whether the pump, pipe connection is sealed, whether the internal smooth or the existence of dry gravel, dry ash, nails, vegetation, etc., ball valve, rubber hose is damaged.
(3)Check the wire, the fuse is intact, and the motor steering is right (clockwise).
2. The use of mortar pumps
First with a white paste as pipe lubrication, using the pump cylinder pressure transmission, and then drive into the more dilute mortar (consistency of 12 cm or more), and finally increased to the desired consistency, so as not to plug the pipeline, especially for the use of new pipes is more important. When using, open the pump first and then add mortar. (Consistency weighing 300 grams)
3. Precautions when using mortar pump
(1)When using, we should always pay attention to the work of the pressure gauge, when the working pressure is over, stop working. At this time should immediately open the pressure relief ball valve, so that pressure drops, eliminate the trouble, and then restart and use.
(2)Should always check the connection hose, flange, and asbestos cord, so that the pressure does not occur leakage.
(3)The cement paste should have sufficient fluidity and recommend for use with a fluidity tester. When the water-cement ratio of 0.4-0.45, the flow of 120-170mm, meets the grouting requirements. Cement may not be doped with chloride, sulfide, and nitrate.
(4)Mortar with sand should be screened, the maximum material diameter is not more than 5 mm. When used, should be mixed uniform, with no dry sand, lumps, stones, and other debris (such as nails, vegetation, etc.).
Recommended mortar ratio:
