Advantage:
1. This is a high-effective shotcrete machine, which is mainly used for dry-mix, damp-mix shotcreting and steel fiber reinforced shotcreting.
2. Nonadhesion going through the rotor with the new material chamber, completely eliminating bonding and blocking during operation so as to reduce clearance and maintenance period.
3. Fourpoint clamping device makes it easy to adjust the press between the sealing plate and rotor disk so as to no air and dust leak and prolong consumption parts life.,
4. Thin flow conveying method with vortex flow, so the spraying flow is even, continuous and steady, to improve the concrete quality.
Specification:
Item PZ-5B PZ-7B
Output5m3/h7m3/h
Max. convey distHorizontal:200m Vertical: 20mHorizontal:200m Vertical: 20m
Water cement ratio≤0.4≤0.4
Max. Aggregate. size20mm20mm
Hose inner size51mm64mm
Operating air pressure0.4~0.6MPa0.4~0.6MPa
Air consumption7-8 m3/min8-10 m3/min
Rotor diameter438mm480mm
Motor powerY132m-6-5.5(KW)Y160m-6-7.5KW
Voltages380v or as your requirement380v or as your requirement
Overall dimension(mm)1600X700X11501600X700X1150
Whole weight800kgs900kgs
Function introduction:
Shotcrete machines are divided into two major categories, that is explosion-proof type and non-explosion-proof type, both are based on straight-through-type rotor blanking under the rotor material, can take full advantage of the role of air force jet to ensure the smooth discharge. The rotor chamber and the discharge elbow materials are made of flexible rubber abrasion. When working, under the action of the pressure can be rushed to the self-cleaning effect, reducing adhesive material and congestion, greatly reducing the maintenance workload of the machine
The machines set the advantages of wet and dry spray machines at home and abroad in one, it is easy to operate, sprays evenly, and has the advantage of low dust, and low rebound.
It optimized the working environment and improved the quality of the spray layer.
