Upset Forging Machine|used In Rebar Bending

We provide true forging versatility by offering upset forging capabilities. Upset forging is a manufacturing process that plastically deforms metal under great pressure into high-strength components of varying sizes. This forging process is ideal for longer shapes where only one end of a part needs to be forged.

Upset forging machines are made by gathering material to a designated area of carbon, alloy, or stainless steel bar. The mechanical press used to manufacture these components operates on a horizontal plane. The dies are split to allow material to protrude beyond the mechanical press, and some of the forming force is provided by a third die attached to the header.

Our upset forgings offer greater strength compared to when the same parts are machined from bar stock since material grain flow is orientated to the component's shape.

The majority of bolting and fastener components used in the industry today are manufactured using the Upset Forging process. There are two types of processes, horizontal split die upset forging and vertical closed die upset forging. The image above shows some of the head styles that can be achieved. Variations of these styles are also common, supplied as forged usages to many machinists and engineers worldwide.

Diameter of upset forging machine:

• 1” Upset Forging Machines

• 1 ½” Upset Forging Machines

• 4” Upset Forging Machines*

• 5” Upset Forging Machines*

• 6” Upset Forging Machines*

• 7” Upset Forging Machines*

• 7 ½” Upset Forging Machines*

• Tube Forging Cell*
