Wholesale BW250 Triplex Mud Pump

Wholesale BW250 Triplex Mud Pump

250 piston mud pump is low noise, no dust, an environment-friendly high pressure grouting machine in construction.

Inquiry

  • Product Details

Wholesale BW250 Triplex Mud Pump

Type BW-250 (grouting machine) mud pump is a horizontal three cylinder reciprocating single acting piston pump, the pump has two cylinder and four gear speed. Displacement and Drilling depth according to the use of random adjustment, the depth of up to 1500 meters, with the drilling rig to use, and can also be used for cement slurry infusion. BW250 drilling mud pump has less energy consumption, flexible operation, high quality and durable, good decomposability and easy to move.

Main parameters of BW250mud pump:

Flow 250L/min

Pressure 80kg/cm2

Drive power 15kw

Water pipe diameter 75mm

Drainage pipe diameter 50mm

Drilling hole deep diamond into <1500

Mass alloy drilling <1000

Shape size 1100*995*650

Weight 760kg

Main features of BW250 mud pump well drilling:

1. the loss of the machine is less, the quality of the vulnerable parts is improved, and the construction cost is greatly reduced.

2. the speed of feeding and discharging is fast. As long as the proportion of concrete is suitable, the material can be guaranteed and the approximate theoretical discharge can be reached.

3. 250 piston mud pump is low noise, no dust, an environment-friendly high pressure grouting machine in construction.

BW250mud pump.jpg

Use of BW250 Triplex Mud Pump:

1. In construction engineering, it is used for vertical and horizontal delivery of mortar.

2. In the metallurgical iron and steel department, it is used for the maintenance of blast furnace and other equipment.

3. It is used in the construction of national defense, civil air defense, mine and tunnel construction.

4. In the chemical industry, it is used to transport slurry materials (color pulp, paint), magnetic materials and other media.

5. In the farmland water conservancy project, it is used to reinforce the dam. Sand drilling is used to reinforce the wall of the well and so on.

6. In railway construction, it is used for the grouting and reinforcement of bridges and culverts.

7. The prestressed component engineering is used for the injection and expansion of the mortar and so on.

8. In the thermal power plant, it is used to transport fly ash grout.

9. In the maintenance of road surface, it is used for cement concrete pavement bottom blank grouting.


Hot Tags: wholesale bw250 triplex mud pump, manufacturers, suppliers, factory, wholesale, buy, cheap, low price
